Number 1 marks the part’s position in the exploded view (Volkswagen GOLF VAR./VENTO (1996-1999)).
Product overview
028103101P Genuine OEM Volkswagen 6-Speed Manual Transmission, part number 02S300047L. This transmission transfers power from the engine to the drive wheels, allowing for changes in speed and torque. It is a complex assembly of gears, shafts, and synchronizers. Manufactured to precise specifications for smooth gear changes and reliable operation. Genuine OEM transmissions ensure correct gear ratios and durability.
Technical details
- Category
- Engine
- Customs (HS) code
- 84099900
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 39 × 33.5 × 29.5 cm
- Shipping weight
- 45 kg
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
5 vehiclesCylinder Block With Pistons — locate 028103101P 02S300047L Volkswagen Transmission | Genuine OEM in the official exploded view and explore the surrounding assembly.
Parts in this assembly44
- 1Cylinder Block 028103101AD
- 1Cylinder Block 028103101AC
- 2Bolt N90130001
- 2Bolt N10263801
- 3Cover 036103113A
- 4Cover N0119077
- 5Cylinder Pin 026103139
- 5Sleeve 028103039A
- 7Seal Ring 056905261
- 8Bush 056103541
- 9Rivet N0162011
- 9Bungs 056103117
- 10Bracket 028905256
- 11Washer N0122293
- 12Bolt N01024416
- 13Seal 068103085E
- 14Washer N01224110
- 15Bolt N01024016
- 16Washer N0122265
- 17Bolt N01021612
- 19Seal 026103161B
- 20Part N0432072
- 21Vent 028103157
- 21Vent 068103157D
- 22Screw N90241501
- 24Flange 068103171F
- 25Seal 026103181B
- 26Sleeve 022103139
- 27Oil Sump 051103601
- 28Seal 044103609D
- 28Lock 037115220B
- 29Seal Ring N0138492
- 30Plug N90288901
- 31Bolt N90592703
- 32Spacer Pl 068105551
- 32Spacer Pl 06B103551
- 35Cover 068103648K
- 35Cover 038103648A
- 36Bolt N0102276
- 37Cover 068103621E
- 38Coverplate 038103645A
- 40Bolt N0102085
- 41Tube 028103634
- 42Funnel 028103663B
Vehicle fitment table5
Europe (5)
| Vehicle | Years | Pos. | Qty | Remark |
|---|---|---|---|---|
| GOLF VAR./VENTO | 1996-1999 | 1 | 1 | AFN |
| Golf | 1996-1997 | 1 | 1 | AFN |
| Golf 96 | 1995-1996 | 1 | 1 | AFN |
| Golf Var./Vento 96 | 1995-1996 | 1 | 1 | AFN |
| Passat | 1994-1997 | 1 | 1 | AFN |
Diagrams & fitment data powered by oemdiagrams.com
028103101P 02S300047L Volkswagen Transmission | Genuine OEM is fitted on: GOLF VAR./VENTO 1996-1999; Golf 1996-1997; Golf 96 1995-1996; Golf Var./Vento 96 1995-1996; Passat 1994-1997.
