Number 9 marks the part’s position in this exploded view (Audi A5 Limousine (2024-2025)).
Other diagrams in the gallery may use a different number for the same part.
Product overview
Genuine OEM Volkswagen Hexagon Flange Screw, part number WHT010141. Fits SEAT CUPRA Born (2021), Audi A5 Avant (2024-2025), Audi A5 Limousine (2024-2025), Volkswagen ID.3 (2019-2025). Shown as position 9 in the wheels and brakes diagram 8WY615030.
Catalogue entry: SCREW M8X1X22.5 ×4.
Fitted with: 1EA615123 HOUSING, 1EA615124 HOUSING, 1EA698151 BR. LINING, 1EA698151L BR. LINING, N91084901 SCREW, 1EA615125 PLATE BRAK, N10648301 BOLT, 1EA615301 BRAKEDISC, 1EA615311C COV. PLATE, 1EA615312C COV. PLATE, WHT005227 BOLT.
Technical details
- Category
- Brakes
- Diagram sheet
- Audi 8wy615030, position 9
- ETKA group
- 6 / 15 (615)
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
Specifications
As recorded in the manufacturer’s parts catalogue for this part number.
- Thread
- M8x1x22.5 mm
