Number 17 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Hex Collared Bolt, part number N10691501. This bolt features a hexagonal head and a collar, designed for fastening components within the engine bay, specifically for mounting the air filter housing. It is identified as part 17 in the diagram. The bolt has a length of 0.128 meters and a weight of 0.0765 kg. Genuine OEM bolts are manufactured to precise tolerances, ensuring proper thread engagement and preventing damage to the air filter housing or mounting points.
Catalogue entry: BOLT M10X118 ×2.
Fitted with: 06F199207Q SUPPORT, N10643801 BOLT, N10552404 BOLT.
Technical details
- Category
- Engine
- Country of origin
- Italy
- Customs (HS) code
- 73181588
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 12.8 × 2.2 × 2.2 cm
- Shipping weight
- 0.08 kg
Specifications
As recorded in the manufacturer’s parts catalogue for this part number.
- Thread
- M10x118 mm
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
42 vehiclesHex Collared Bolt — locate N10691501 Volkswagen Hex Collared Bolt | Engine Mount in the official exploded view and explore the surrounding assembly.
Standard part (a norm part such as a bolt, nut or clip) — used across many models; the vehicle list shows where this exact number is fitted.
Parts in this assembly21
- 1Bracket 5C0199313R
- 2Rubber Bush 1K0199868R
- 3Rubber Bush 1K0199867R
- 5Bolt N91208401
- 6Bolt N10579702
- 6Screw N91143301
- 7Eng MountiRight1K0199262AM
- 8Bolt N10706901
- 9Bolt N91029602
- 10SupportRight1K0199588
- 11Bolt N01950213
- 12SupportRight06F199207Q
- 13Bolt N10655802
- 15Bolt N10552404
- 17Gear MountLeft1K0199555CE
- 20ConsoleLeft1K0199117AB
- 22Bolt N10623701
- 27Support 1K0199855BF
- 28Bolt N91167101
- 29Bolt N91066101
- 30Bolt N10558002
Vehicle fitment table43
Europe (32)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| jetta 2.0 | 2015-2015 | 14 | 1 | ||
| jetta | 2014-2017 | 11 | 1 | ||
| Golf Plus | 2011-2014 | 14 | 1 | BSE,BSF, | |
| Golf | 2011-2013 | 14 | 1 | BSE,BSF, | |
| Caddy Maxi Kombi | 2010-2015 | 17 | 1 | BSF,BSX,CHGA | |
| jetta | 2010-2014 | 11 | 1 | ||
| golf estate | 2009-2013 | 14 | 1 | ||
| Golf Plus 1.6 | 2009-2011 | 14 | 1 | ||
| golf 2.0 | 2008-2011 | 14 | 1 | ||
| passat estate | 2008-2011 | 14 | 1 | BSE,BSF | T53 |
| jetta | 2008-2011 | 14 | 1 | BSE,BSF,CCSA | T53 |
| caddy panel van | 2008-2010 | 14, 17 | 1 | BSE,BSF,BSX | TN2 |
| Sharan | 2008-2010 | 15 | 3 | AWC,ATM | |
| Touran 1.9 | 2008-2010 | 14 | 1 | BSE,BSF,BSX | TN2 |
| Polo | 2008-2009 | 21 | 1 | BNM,BNV,BWB, | |
| GOLF VARIANT 07> | 2007- | 14 | 1 | BSE,BSF,CCSA | T53 |
| GOLF PLUS 08> | 2007- | 14 | 2 | BSE,BSF,CCSA | |
| Passat/4Motion 08 | 2007- | 14 | 1 | BSE,BSF | T53 |
| JETTA 06> | 2006- | 14 | 1 | BSE,BSF | |
| TOURAN | 2006- | 14 | 1 | BSE,BSF,BSX | TN2 |
| GOLF PLUS 05> | 2005- | 14 | 1 | BSE,BSF | T53 |
| POLO | 2005- | 21 | 1 | BNM,BNV,BWB, | |
| SHARAN/4MOTION | 2005- | 15 | 3 | AWC,ATM | |
| JETTA 06> | 2005- | 14 | 1 | T53 | |
| Passat/4Motion | 2005-2007 | 14 | 1 | BSE,BSF | T53 |
| TOURAN | 2005-2006 | 14 | 1 | BSE,BSF,BSX | TN2 |
| CADDY | 2004- | 14 | 1 | BGU,BSE,BSF, | TN2,T53 |
| GOLF | 2003-2005 | 14 | 1 | ||
| LUPO/3L TDI | 2003-2005 | 18, 19 | 2 | T4A | |
| SHARAN/4MOTION | 2002-2005 | 15 | 3 | AWC,ATM | MG8 |
| POLO | 2001-2005 | 3 | |||
| SHARAN/SYNCRO | 1995-2000 | 24 | 3 | AJH |
Other markets (10)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| bora | 2008-2016 | 21 | 1 | BWH,CEN | TC2 |
| MAGOTAN (PASSAT) 07> | 2007- | 14 | 1 | BJZ | TE2 |
| Golf/Rabbit 08> | 2007- | 14 | 1 | BSE,BSF,CCSA | T53 |
| CADDY-FAW "CN" 05> | 2005- | 14 | 1 | BRY | |
| BORA-FAW "CN" 06> | 2005- | 14 | 1 | BWH,BJZ | TC2 |
| POLO CLASSIC "ZA"05> | 2005- | 21 | 1 | BNM,BNV,BWB, | |
| Golf/Rabbit | 2005-2007 | 14 | 1 | BSE,BSF | T53 |
| TOURAN (SVW) "CN"04> | 2004- | 14 | 1 | BJZ,CGZA | D3R |
| POLO CLASSIC "ZA"03>05 | 2003-2005 | 21 | 1 | BAY,AMF | |
| MARINE-MOTOR 02> | 2002- | 40, 7, 9, 6 | X |
Listed without a diagram position (1)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| LUPO/3L TDI | 1998-2003 | 18 | 2 |
